PALL实验室Acro 500除菌囊式滤器新产品上市
2023-03-14 来源:本站 点击次数:3394
PALL实验室近期推出Acro 500除菌囊式滤器为您带来低蛋白吸附和快速高效的生物样品过滤。
Acro 500 是带有Supor EKV膜材和聚碳酸酯外壳的囊式滤器，在除菌过滤大体积实验室料液中为您带来500 cm2 有效过滤面积(EFA)。囊式滤器使用双层PES聚醚砜膜材构成，从而提供快速和高效的过滤。
膜材的低蛋白吸附特性带来最大的活性样品组分的传输同时带来最广泛的液体兼容性，适用于过滤一系列样品包括缓冲液，生物料液以及细胞培养基。
带有聚碳酸酯的外壳, 提高的光学透明度为您带来更加方便的排气，从而最大化使用膜面积，从而带来流速和通量的优化。
Specifications
Materials of Construction
Filter Media: Supor EKV membrane (hydrophilic polyethersulfone)
Housing: Polycarbonate
Filter Support: Polyester
Core & Vent Plug: Polypropylene
Sealing Technology: Polyurethane
Pore Size
0.65/0.2 µm
Effective Filtration Area
500 cm2
Dimensions
Overall Length: 13.3 cm (5.2 in.)
Diameter: 6.0 cm (2.4 in.)
Inlet/Outlet Connections
Hose Barb fittings accept 12.7 mm (1/2 in.) ID tubing
Endotoxin Level
< 0.25 EU/mL utilizing Limulus Amebocyte Lysate (LAL) test
Minimum Water Flow Rate
0.7 L/min at 0.1 bar (10 kPa, 1.5 psi)
Hold-up Volume (with Air Purge)
≤ 30 mL
Maximum Operating Pressure
3.4 bar (340 kPa, 50 psi) at ambient temperature
Maximum Operating Temperature
60 °C (140 °F) at 2.1 bar (210 kPa, 30 psi)
Recommended Integrity Test Minimum Bubble Point- IPA / Water (60/40 v/v)
1.2 bar (120 kPa, 17 psi)
Bacterial Retention
Lot samples retain a minimum 107 cfu/cm2 of B. diminuta per modified ASTM F838, current revision.
Sterilization
Sterilized by gamma irradiation and individually packed.
Do NOT autoclave
